SCHNEIDER LV431782, circuit breaker Compact NSX250F - TMD - 250 A - 3 poles 2d
This Compact NSX250F is a complete 3P 2d fixed circuit breaker designed to optimize space and breaking capacity.

It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz.

This product embeds a 250A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection.

This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Compact NSX250F is part of Schneider Electric Eco Structure Power architecture.

Part No. : LV431782

(G13-WA3)
